| Items | Parameters | Remarks |
| Main motor power | 7.5kw | two poles |
| Feeding motor power | 1.5kw | six poles |
| worm wheel decelerator | 60:1 100model | 2.5 model |
| Spindle velocity | 2000RPM | |
| Feeding speed | 1.5/2.2m/min | Double pulling gear, 2 in 2 out |
| Cutting diameter | 50-150mm | Square section material |
| Max.cutting quantity | 2mm (semidiameter) | |
| Min.working length | 1000mm | |
| Overall dimension | 1852 x 860 x 1230mm | |
| Machine weight | 1100kg |
